(TC09-947) 2010-2013 CK1 КРЕПЛЕНИЕ КОМПРЕССОРА КОНДИЦИОНЕРА (LZ1/6.0J)
| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена | | 001 | | MODULE, DRV MOT GEN PWR INV (SEE GROUP 02.000 "CONTROL MODULE ASM/DRIVE MOTOR" FOR DETAILED ILLUSTRATED VIEW) | | 2008-2013 | | | | | 002 | 11588711 | BOLT, HFH, M6X1X16, 10 THD, 14.2 OD, 8.8 STL, GMW3359 (PART OF 6) | | 2008-2013 | 02 | | узнать цену | | 003 | | BOLT, A/C CMPR (300 V) CBL (PART OF 6) | | 2010-2013 | | | | | 004 | 25932364 | CABLE KIT, A/C CMPR (300 V) (PART OF 6) (INCLS 18) | CK1 (LZ1, CJ2) | 2010-2013 | 01 | | узнать цену | | 005 | 11588711 | BOLT, HFH, M6X1X16, 10 THD, 14.2 OD, 8.8 STL, GMW3359 (PART OF 6) | | 2008-2013 | 01 | | узнать цену | | 006 | 25880380 | COMPRESSOR KIT, A/C (INCLS 2-5, 11, 13, 14, 16-19) | CK1 (LZ1, CJ2) | 2010-2013 | 01 | | узнать цену | | 007 | 11515767 | BOLT, HFH, M10X1.5X35, 32THD, 22.3 O.D., MACH, 10.9, 7114M (A/C CMPR BRKT) (T/W 12345493) | | 2008-2013 | 03 | | узнать цену | | 008 | 12612834 | BRACE, A/C CMPR BRKT | CK1 (LZ1, CJ2, HP2) | 2010-2013 | 01 | | узнать цену | | 009 | 11518631 | BOLT, HFH, M10X1.5X65, 26 THD, 22.3 OD, 10.9 STL, GMW3359 (A/C CMPR) | | 2008-2013 | 03 | | узнать цену | | 010 | 12609916 | BRACKET, A/C CMPR | CK1 (LZ1, CJ2, HP2) | 2010-2013 | 01 | | узнать цену | | 011 | | LABEL, HIGH VOLTAGE WRNG (PART OF 6) | | 2010-2013 | | | | | 012 | 11571051 | BOLT, HFH, M10X1.5X45, 26 THD, 19 OD, 10.9, GMW3359 M-PT. (A/C CMPR BRKT BR) | | 2008-2013 | 03 | | узнать цену | | 013 | | SEAL, A/C CMPR CBL BLOCK (O-RING) (PART OF 6) | | 2010-2013 | | | | | 014 | | BOLT, A/C CMPR (300 V) CBL (PART OF 6) | | 2010-2013 | | | | | 015 | 15753766 | CLIP, A/C CMPR WRG HARN (1.540) | CK1 (HP2) | 2008-2013 | 01 | | узнать цену | | 016 | | CLIP, A/C CMPR WRG HARN (PART OF 6) | | 2010-2013 | | | | | 017 | | BRACKET, A/C CMPR CBL (PART OF 6) | | 2010-2013 | | | | | 018 | 25880383 | SEAL, A/C CMPR CBL BLOCK (O-RING) (PART OF 4, 6) | CK1 (LZ1, CJ2) | 2010-2013 | 01 | | узнать цену | | 019 | 15208784 | VALVE, A/C CMPR PRESS RLF (PART OF 6) (ACDelco #15-50421) | CK1 (LZ1, CJ2) | 2010-2013 | 01 | | узнать цену | | 020 | 11609226 | STUD, A/C CMPR (M10X1.5X14) (0.029) | CK1 (LZ1) | 2010-2013 | 01 | | узнать цену |
|
|
