(6N03-025) 2011 N СИСТЕМА ВПУСКА ВОЗДУХА (LF1/3.0Y)
| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена | | 001 | | COVER, A/CL HSG (PART OF 9) | | 2011-2011 | | | | | 002 | | CLAMP, A/CL OTLT DUCT (PART OF 3) | | 2011-2011 | | | | | 003 | 20850108 | DUCT, A/CL OTLT (W/RESO) (INCLS 2) | N (LF1) | 2010-2011 | 01 | | узнать цену | | 004 | 12630821 | TUBE, PCV (FRESH AIR) | N (LF1) | 2010-2011 | 01 | | узнать цену | | 005 | 19168954 | CLIP, A/CL HSG | N (LAU, LF1) | 2010-2011 | 04 | | узнать цену | | 006 | 11570295 | RETAINER, A/CL (M6X1X28, 10 THD, 17) | N | 2010-2011 | 03 | | узнать цену | | 007 | 11515174 | SEAL, INT AIR DUCT (4 1/4" X 7 1/2") (TRIM AS REQ'D) (OUTBOARD) (12.941) | N | 2010-2011 | 02 | | узнать цену | | 008 | 15913320 | DUCT, FRT INT AIR | N (LAU, LF1) | 2010-2011 | 01 | | узнать цену | | 009 | 20897356 | CLEANER, AIR (INCLS 1, 10, 11) | N (LF1) | 2011-2011 | 01 | | узнать цену | | 010 | 12563914 | INSULATOR, A/CL HSG (PART OF 9) (MOUNT TO MID RAIL) | N (LAU, LF1) | 2010-2011 | 01 | | узнать цену | | 011 | 20897358 | ELEMENT, A/CL (PART OF 9) (W/O HYDROCARBON) (ACDelco #A3147C) | N (LAU, LF1) | 2010-2011 | 01 | | узнать цену | | 012 | 15813321 | GASKET, MASS AIRFLOW SEN (PART OF 13) (RECTANGULAR) (GASKET IS POA TO MAF SENSOR) (ACDelco #15813321) | N (LF1) | 2011-2011 | 01 | | узнать цену | | 013 | 15865791 | SENSOR, MASS AIRFLOW (W/INT AIR TEMP SEN) (INCLS 12) (5 PIN) (ACDelco #213-4222) | N (LF1) | 2010-2011 | 01 | | узнать цену | | 014 | 15809005 | BOLT, MASS AIRFLOW SEN (D40X1.46X12, 9.5THD) | N (LAU, LF1) | 2010-2011 | 02 | | узнать цену | | 015 | | SEAL, THROT POSN SEN (PART OF 16) | | 2011-2011 | | | | | 016 | 12591290 | SENSOR, THROT INL ABSOLUTE PRESS (INCLS 15) (ACDelco #213-3842) | N (LF1) | 2011-2011 | 01 | | узнать цену | | 017 | 11610718 | BOLT, THROT INL ABSOLUTE PRESS SEN | N (LF1) | 2010-2011 | 01 | | узнать цену | | 018 | 20807093 | SHIELD, INT AIR SPH | N (LF1) | 2010-2011 | 01 | | узнать цену | | 019 | 11589295 | RETAINER, INT AIR SPH SHLD (PUSH IN) (PUSH PIN RETAINER) (FITS 10.5 HOLE, 3-6.0 THK PNL) (8.950) | N (LAU, LF1) | 2010-2011 | 02 | | узнать цену |
|
|
