| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена |
| 001 | 22824224 | CARRIER, DIFF (CODE 0105 4224) (INCLS 2-43) (FOR VEH W/O INBOARD SLINGERS ORDER T/W SEAL 20986535 (QTY 2)) | N (LFW, F46) | 2012-2012 | 01 | | узнать цену |
| 001 | 22931259 | CARRIER, DIFF (CODE 0104 1259 4223) (INCLS 2-43) (FOR VEH W/O INBOARD AXLE SHF SLINGERS & W/ BLK AXLE SHF SEALS ORDER T/W 20986535 (QTY 2) | N (LFX, F46) | 2012-2012 | 01 | | узнать цену |
| 001 | 22931260 | CARRIER, DIFF (CODE 1260) (INCLS 2-43) (FOR VEH W/O INBOARD AXLE SHF SLINGERS & W/ BLK AXLE SHF SEALS ORDER T/W 20986535 (QTY 2) | N (LFW, F46) | 2012-2012 | 01 | | узнать цену |
| 002 | 22897038 | DIFFERENTIAL, L/SLIP (INCLS 3-13, 15, 16, 40, 42, 43) | N (LFW, LFX, F46) | 2012-2012 | 01 | | узнать цену |
| 003 | 22952053 | VENT, DIFF (PART OF 2) | N (F46) | 2010-2013 | 01 | | узнать цену |
| 004 | 15842651 | PIN, DIFF CARR LOC (PART OF 2) (5.510) | N | 2010-2013 | 02 | | узнать цену |
| 005 | | GASKET, L/SLIP DIFF CLU CASE (PART OF 2, 6) (*KIT4) | | 2010-2013 | | | |
| 006 | 22896612 | CLUTCH, L/SLIP DIFF (REFER TO PI0703 FOR ADDL PART & RPR GUIDANCE PRIOR TO ORDER) (PART OF 2) (INCLS 5, 7-10) (FOR VEH W/O INBOARD SLINGERS ORDER T/W SEAL 20986535 (QTY 1)) (FOR USE ON VEH'S W/ INBOARD AXLE SHAFT SLINGERS & W/ YELLOW AXLE SHAFT SEAL) (FOR 1ST DESIGN SEE 22863114) | N (LFW, LFX, F46) (2ND DES) | 2012-2012 | 01 | | узнать цену |
| 006 | 22863114 | CLUTCH, L/SLIP DIFF (REFER TO PI0703 FOR ADDITIONAL PART & REPAIR GUIDANCE PRIOR TO ORDER) (PART OF 2) (INCLS 5, 7-10) (FOR USE ON EARLY 2012 & PRIOR VEH'S W/O INBOARD AXLE SHAFT SLINGERS & W/ BLACK AXLE SHAFT SEAL) (FOR 2ND DESIGN SEE 22896612) | N (LFW, LFX, F46) (1ST DES) | 2012-2012 | 01 | | узнать цену |
| 007 | | GASKET, L/SLIP DIFF CLU VLV HSG (PART OF 2, 6, 9) (*KIT4) | | 2010-2013 | | | |
| 008 | 13280084 | BOLT, L/SLIP DIFF CLU VLV HSG (PART OF 2, 6, 9) | N | 2010-2013 | 02 | | узнать цену |
| 009 | 13280097 | VALVE KIT, L/SLIP DIFF CLU (PART OF 2, 6) (INCLS 7, 8) | N | 2010-2013 | 01 | | узнать цену |
| 010 | 13280079 | BOLT, L/SLIP DIFF CLU (PART OF 2, 6) | N | 2010-2013 | 01 | | узнать цену |
| 011 | 20986535 | SEAL, R/AXL SHF (PART OF 2) (BLACK) (USED ON EARLY 2012 VEH W/O INBOARD AXLE SLINGERS) (FOR 2ND DESIGN SEE 22845699) | N (LFW, LFX, F46) (1ST DES) | 2012-2012 | 02 | | узнать цену |
| 011 | 22845699 | SEAL, R/AXL SHF (PART OF 2) (YELLOW) (ACDelco #291-332) (USED ON LATE 2012 VEH W/ INBOARD AXLE SLINGERS) (FOR 1ST DESIGN SEE 20986535) | N (LFW, LFX, F46) (2ND DES) | 2012-2012 | 02 | | узнать цену |
| 012 | | GASKET, DIFF CARR FILL PLUG (PART OF 2, 13) | | 2010-2013 | | | |
| 013 | 55573646 | PLUG, DIFF CARR FILL (PART OF 2) (INCLS 12) (M20X1.5X16, 29 OD) (SQ HD W/WASHER, W/MAGNET) (ZINC COATED) (4.510) | N (F46) | 2012-2013 | 01 | | узнать цену |
| 014 | 13280061 | BOLT, DIFF CLU (PART OF 30) | N | 2010-2013 | 04 | | узнать цену |
| 015 | | GASKET, R/AXL HSG DRN PLUG (PART OF 2, 16) | | 2010-2013 | | | |
| 016 | 55573646 | PLUG, DIFF CARR DRN (PART OF 2) (INCLS 15) (M20X1.5X16, 29 OD) (SQ HD W/WASHER, W/MAGNET) (ZINC COATED) (4.510) | N (F46) | 2012-2013 | 01 | | узнать цену |
| 017 | | SEAL, L/SLIP DIFF CLU PIPE CONN (PART OF 18) (*KIT1) | | 2010-2013 | | | |
| 018 | 13280086 | CONNECTOR, L/SLIP DIFF CLU PIPE (INCLS 17, 19, 20) (*KIT1) | N | 2010-2013 | 04 | | узнать цену |
| 019 | 13280087 | SPRING, L/SLIP DIFF CLU PIPE CONN (PART OF 18) (*KIT1) | N | 2010-2013 | 04 | | узнать цену |
| 020 | | SEAL, L/SLIP DIFF CLU PIPE CONN (PART OF 18) (*KIT1) | | 2010-2013 | | | |
| 021 | | PIPE, L/SLIP DIFF CLU LOW PRESSURE (*KIT1) | | 2010-2013 | | | |
| 022 | | PIPE, L/SLIP DIFF CLU HIGH PRESSURE (*KIT1) | | 2010-2013 | | | |
| 023 | 13280059 | BOLT, RR DIFF CLU CONT MDL (PART OF 30) (M5X.8X35, 11 OD) | N | 2010-2013 | 02 | | узнать цену |
| 024 | | BOLT, DIFF CLU PUMP (PART OF 25, 30) | | 2010-2013 | | | |
| 025 | 22765779 | PUMP KIT, DIFF CLU (PART OF 30) (INCLS 24) | N | 2010-2013 | 01 | | узнать цену |
| 026 | 22820678 | MODULE KIT, RR DIFF CLU CONT (INCLS VALVE) | N | 2012-2012 | 01 | | узнать цену |
| 027 | | FLANGE, PROP SHF (PART OF 30) (*KIT2) | | 2010-2013 | | | |
| 028 | | NUT, PROP SHF FLG (PART OF 30) (*KIT2, KIT3) | | 2010-2013 | | | |
| 029 | | COVER, DIFF CLU RR (PART OF 30) (*KIT3, KIT4) | | 2010-2013 | | | |
| 030 | 22820680 | CLUTCH, DIFF (STAMPED 22820680) (INCLS 14, 23-25, 27-29, 31-39) | N (LFX, F46) | 2012-2012 | 01 | | узнать цену |
| 030 | 22820681 | CLUTCH, DIFF (INCLS 14, 23-25, 27-29, 31-39) | N (LFW, F46) | 2012-2012 | 01 | | узнать цену |
| 031 | | SEAL, DIFF CLU CASE PLUG (PART OF 30) | | 2010-2013 | | | |
| 032 | | PLUG, DIFF CLU CASE (PART OF 30) | | 2010-2013 | | | |
| 033 | | FILTER, DIFF CLU OIL (PART OF 30) (*KIT5) | | 2010-2013 | | | |
| 034 | | GASKET, DIFF CLU CVR (PART OF 30) (*KIT3, KIT4, KIT5) | | 2010-2013 | | | |
| 035 | | COVER, DIFF CLU (PART OF 30) | | 2010-2013 | | | |
| 036 | 13280045 | PLUG, DIFF CLU CVR (PART OF 30) | N | 2010-2013 | 01 | | узнать цену |
| 037 | | SEAL, DIFF CLU CVRPLUG (PART OF 30) | | 2010-2013 | | | |
| 038 | 13280041 | BOLT, DIFF CLU CVR (PART OF 30) | N | 2010-2013 | 10 | | узнать цену |
| 039 | 13326736 | VENT, DIFF CLU (PART OF 30) | N | 2010-2013 | 01 | | узнать цену |
| 040 | 13296280 | SEAL, DIFF DRV P/GR (PART OF 2) | N | 2010-2013 | 01 | | узнать цену |
| 041 | 20873360 | BUSHING, DIFF CARR (FRONT) | N (LFX, LFW, F46) | 2012-2013 | 01 | | узнать цену |
| 042 | | CASE, DIFF (PART OF 2) | | 2010-2013 | | | |
| 043 | 13280065 | BOLT, DIFF CASE (PART OF 2) (5.506) | N | 2010-2013 | 10 | | узнать цену |
| 043 | 13280065 | BOLT, DIFF CASE (PART OF 2) | N | 2010-2013 | 10 | | узнать цену |
| 043 | 13280065 | BOLT, DIFF CASE (PART OF 2) (5.506) | N | 2010-2013 | 10 | | узнать цену |
| K01 | 20813559 | PIPE KIT, L/SLIP DIFF CLU (INCLS 17-22) | N | 2010-2013 | 01 | | узнать цену |
| K02 | 13334081 | FLANGE KIT, PROP SHF (INCLS 27, 28) (PLASTIC DIFFERENTIAL DUST COVER) | N (LFW, F46) | 2012-2013 | 01 | | узнать цену |
| K02 | 20917127 | FLANGE KIT, PROP SHF (INCLS 27, 28) | N (LFX, F46) | 2012-2013 | 01 | | узнать цену |
| K03 | 13334079 | SEAL KIT, DIFF CLU (INCLS 28, 29, 34) | N | 2010-2013 | 01 | | узнать цену |
| K04 | 13334078 | SEAL KIT, DIFF (INCLS 5, 7, 29, 34) | N | 2010-2013 | 01 | | узнать цену |
| K05 | 20986573 | FILTER KIT, DIFF CLU OIL (INCLS 33, 34) (INCLS FILTER AND GASKET) | N (F46) | 2010-2013 | 01 | | узнать цену |
