(6D13-002) 2005-2011 D29 ЖГУТ ПРОВОДОВ/КУЗОВ
| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена | | 001 | 20920463 | HARNESS, BODY WRG (INCLS 2, 5, 8, 10, 14-18) | DW29 (YQ4) | 2009-2011 | 01 | | узнать цену | | 001 | 20977735 | HARNESS, BODY WRG (INCLS 2, 5, 8, 10, 14-18) | DW29 (YQ4) (EXC UFL) | 2011-2011 | 01 | | узнать цену | | 001 | 20977736 | HARNESS, BODY WRG (INCLS 2, 5, 8, 10, 14-18) | DW29 (YQ2) (EXC T4F) | 2010-2011 | 01 | | узнать цену | | 001 | 20977739 | HARNESS, BODY WRG (INCLS 2, 5, 8, 10, 14-18) | DW29 (T4F, YQ1, YQ2) | 2011-2011 | 01 | | узнать цену | | 001 | 20977740 | HARNESS, BODY WRG (INCLS 2, 5, 8, 10, 14-18) | DW29 (YQ6) | 2010-2011 | 01 | | узнать цену | | 002 | | BOLT, BODY WRG HARN GND (PART OF 1) | | 2005-2011 | | | | | 003 | | HARNESS, B/U ALARM WRG (SEE GROUP 02.000 "SENSOR SYSTEM/REAR OBJECT" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 004 | | HARNESS, W/S HDR WRG (SEE GROUP 14.000 "ROOF HEADLINER" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 005 | 25744307 | CABLE, DIGITAL RDO ANTENNA (PART OF 1) (1150MM LONG) | D29 | 2005-2011 | 01 | | узнать цену | | 006 | | HARNESS, FUEL SDR WRG (SEE GROUP 03.000 "FUEL TANK & MOUNTING" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 007 | | HARNESS, RR S/D DR WRG (SEE GROUP 10.000 "DOOR HARDWARE REAR" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 008 | | BLOCK, BODY WRG HARN JUNC (PART OF 1) (SEE GROUP 02.000 "RELAYS & MODULES/BODY COMPARTMENT" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 009 | | HARNESS, FRT S/D DR WRG (SEE GROUP 10.000 "DOOR HARDWARE/FRONT" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 010 | 25749070 | CABLE, NAVIGATION ANT COAX EXTN (PART OF 1) (2930MM) (PLUGS INTO ONSTAR CELLULAR CONNECTOR) | D29 | 2005-2011 | 01 | | узнать цену | | 011 | | HARNESS, F/FLR CNSL WRG (SEE GROUP 10.000 "CONSOLE/FLOOR" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 012 | | HARNESS, I/P WRG (SEE GROUP 02.000 "WIRING HARNESS/INSTRUMENT PANEL" FOR DETAILED ILLUSTRATED VIEW) (1150MM LONG) (9.647) | | 2005-2011 | | | | | 013 | | HARNESS, ENG WRG (SEE GROUP 02.000 "WIRING HARNESS/ENGINE" FOR DETAILED ILLUSTRATED VIEW) | | 2005-2011 | | | | | 014 | 25749068 | CABLE, RDO ANT (PART OF 1) (ACDelco #25749068) | D29 | 2005-2011 | 01 | | узнать цену | | 015 | | CABLE, R/CON DR LK COAX (PART OF 1) | | 2010-2011 | | | | | 016 | 25752930 | CABLE, NAVIGATION ANT COAX (VEHICLE RIGHT SIDE) (PART OF 1) (2715MM) (PLUGS INTO GPS PORT) | D29 | 2005-2011 | 01 | | узнать цену | | 017 | | RELAY, WSW MOT (PART OF 1) | | 2010-2011 | | | | | 018 | | GROMMET, BODY WRG HARN (PART OF 1) | | 2008-2011 | | | |
|
|
