(TS06-718) 2004-2012 T СИСТЕМА РУЛЕВОГО УПРАВЛЕНИЯ И СВЯЗАННЫЕ ДЕТАЛИ
| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена | | 001 | | COLUMN, STRG (SEE GROUP 06.000 "STEERING COLUMN" FOR DETAILED ILLUSTRATED VIEW) | | 2004-2012 | | | | | 002 | 11610010 | BOLT, HEX W/ CON WA, M8X1.25X40, 32 THD, 28 OD, 9.8, 7114M, MACH, P-PT (STRG COL) | | 2004-2012 | 02 | | узнать цену | | 002 | 12345382 | COMPOUND, ADHESIVE/SEALANT, THREAD, MED STRENGTH, (6ML) (STRG COL TILT WHL REL LVR) (ACDelco #10-1009) | | 2004-2012 | AR | | узнать цену | | 003 | 15685230 | NUT, STRG COL (8 X 1.25) (W/LOCK WASHER) (8.016) | ST1 | 2004-2012 | 02 | | узнать цену | | 004 | 15170149 | BOLT, INTER STRG SHF UPR (M8X1.25X38.7, 20THD) (INCLS NYLON SLEEVE) | ST1 | 2004-2012 | 01 | | узнать цену | | 005 | 25900714 | SHAFT, LWR STRG | ST1 (LLR, LLV) | 2008-2012 | 01 | | узнать цену | | 005 | 25900715 | SHAFT, LWR STRG | ST1 (LH9) | 2010-2012 | 01 | | узнать цену | | 006 | 26030302 | BOLT, INTER STRG SHF LWR (M10X1.5X39) (HFH NYLON LOCK) (6 POINT HEAD) | ST1 | 2004-2012 | 01 | | узнать цену | | 007 | 11516133 | NUT, S/GR (M16X2X15) (NUT ONLY) (8.917) | ST1 | 2004-2012 | 02 | | узнать цену | | 008 | 11561076 | WASHER, S/GR (ID 16.875 OD 39.5, THK 4.5MM) | ST1 | 2005-2012 | 02 | | узнать цену | | 009 | | GEAR, STRG (W/STRG LNKG TIE ROD) (SEE GROUP 06.000 "STEERING GEAR ASSEMBLY" FOR DETAILED ILLUSTRATED VIEW) | | 2004-2012 | | | | | 010 | 11588326 | BOLT, S/GR (M16X2X187, 57THD) (8.900) | ST1 | 2004-2012 | 02 | | узнать цену | | 011 | 11609295 | BOLT, HFH, W/FL WA, M12X1.75X43, 24 THD, 25.5 OD, 10.9, 7114M, ADH 6175M (S/GR) | | 2004-2012 | 02 | | узнать цену |
|
|
