(TC03-504) - 2003 N2 РАМА ТОПЛИВНОГО ИНЖЕКТОРА (LQ4/6.0U)
|
|
|||||
| Рис. | Номер | Описание | Примен. | Номенкл. | Кол. | Р. | Цена |
| 001 | FUEL RETURN PIPE (*KIT5) | 2003-2003 | |||||
| 002 | RETAINER, FUEL RETURN PIPE (*KIT5) | 2003-2003 | |||||
| 003 | SCREW, FUEL RETURN PIPE ATTACHING (*KIT5) | 2003-2003 | |||||
| 004 | VALVE, FUEL PRESS SERV (*KIT7) | 2003-2003 | |||||
| 005 | RETAINER CLIP, CROSSOVER FUEL PIPE (*KIT4) | 2003-2003 | |||||
| 006 | O-RING, FUEL RETURN PIPE (*KIT6) | 2003-2003 | |||||
| 007 | O-RING, CROSSOVER FUEL PIPE (PART OF 25) (*KIT6) | 2003-2003 | |||||
| 008 | CLIP, REGULATOR RETAINER (*KIT10) | 2003-2003 | |||||
| 009 | CARTRIDGE REGULATOR ASM, FUEL PRESSURE (*KIT10) | 2003-2003 | |||||
| 010 | RING, BACKUP (*KIT10) | 2003-2003 | |||||
| 011 | O-RING, REGULATOR SEAL (*KIT10) | 2003-2003 | |||||
| 012 | FILTER, REGULATOR (*KIT10) | 2003-2003 | |||||
| 013 | O-RING, REGULATOR SEAL (*KIT10) | 2003-2003 | |||||
| 014 | 17113696 | RAIL, M/PORT F/INJN FUEL (ACDelco #17113696) | N257 (06) (LQ4) | 2003-2003 | 01 | L | узнать цену |
| 015 | 17113695 | RAIL, M/PORT F/INJN FUEL (ACDelco #17113695) | N257 (06) (LQ4) | 2003-2003 | 01 | R | узнать цену |
| 016 | O-RING, FUEL INJECTOR UPPER (*KIT9) | 2003-2003 | |||||
| 017 | 17113698 | INJECTOR, M/PORT FUEL (IF REPLACING CONN-USE W/CONN 88988814) (ACDelco #17113698) [ФОРСУНКА, ИНЖЕКТОРА] | N257 (06) (LQ4) | 2003-2003 | 08 | узнать цену | |
| 017 | 19236325 | INJECTOR, M/PORT FUEL (ALL MAKES) | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| 018 | O-RING, FUEL INJECTOR LOWER (*KIT9) | 2003-2003 | |||||
| 019 | 12570620 | RETAINER KIT, F/INJR (W/ 8 RETAINERS) (ACDelco #12570620) | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| 020 | O-RING, CROSSOVER FUEL PIPE (PART OF 25) (*KIT6) | 2003-2003 | |||||
| 021 | RETAINER CLIP, CROSSOVER FUEL PIPE (*KIT4) | 2003-2003 | |||||
| 022 | SCREW, RETAINER CLIP ATTACHING (*KIT4) | 2003-2003 | |||||
| 023 | CAP, FUEL PRESSURE CONNECTION (PART OF 25) (*KIT7) | 2003-2003 | |||||
| 025 | 89017377 | TUBE, F/INJN FUEL RL C/OVR (INCLS 7, 20, 23) | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| 026 | 17113556 | TUBE, FUEL PRESS REG VAC | N257 (06) (LQ4, M32, NC1, NT9) | 2003-2003 | 01 | узнать цену | |
| 026 | 17113699 | TUBE, FUEL PRESS REG VAC (B/C 25323715 ON FUEL PRESS REG) | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| K04 | 89017379 | RETAINER KIT, F/INJN FUEL RL C/OVR TUBE (INCLS 5, 21, 22) | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| K05 | 89017381 | PIPE KIT, F/INJN FUEL RTN (INCLS 1, 2, 3) (3.162) | N257 (06) (LQ4, M32, NC1, NT9) | 2003-2003 | 02 | узнать цену | |
| K06 | 17113552 | SEAL KIT, F/INJN FUEL RL (INCLS 6, 7, 20) (ACDelco #17113552) [ПРОКЛАДКА ИНЖЕКТОРА] | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| K07 | 12570619 | VALVE KIT, FUEL PRESS SERV (INCLS 4, 23) (ACDelco #12570619) [КЛАПАНА] | N257 (06) (LQ4, M32, NC1, NT9) | 2003-2003 | 01 | узнать цену | |
| K09 | 12587147 | SEAL KIT, F/INJR (O RING) (INCLS SEALS) (INCLS 16, 18) (W/ 8 UPPER & 8 LOWER SEALS) (ACDelco #217-1588) [ЗАСЛОНКА] | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену | |
| K10 | 89060420 | REGULATOR KIT, FUEL PRESS (INCLS 8-13) (ACDelco #217-3073) [КЛАПАН КОНТРОЛЯ ВПРЫСКА ТОПЛИВА] | N257 (06) (LQ4) | 2003-2003 | 01 | узнать цену |
